ER-F10004 White waterproof light
Architectural / landscape
PRODUCT DETAILS
All-aluminum structure, no fan, depending on the nature of aluminum alloy radiator cooling, absolutely silent mode design. Delicate and elegant appearance of the structure, with international advanced electronic control technology and excellent user-friendly industrial design. 100W single high-power white LED light source, the light beam angle of 600 ultra-high intensity white light, so powerful features make it ideal for lighting large and small performances, theater, exhibitions, landscape lighting and other places of choice. In addition to DMX control has a powerful RDM control technology.
Optics
LED type: single white LED 100W;
Light beam angle: 600;
Average life expectancy: ≥50,000H;
Colour
Color temperature: CW 6000K (WW 3200K);
effect
Fast electronic strobe: 1 ~ 25 Hz;
Dimming mode: two kinds;
Dimming curve: four kinds;
Control and Programming
Control channel: two kinds of channel mode (1/2);
Protocol: standard DMX512 protocol, RDM protocol;
Data Connection: waterproof three core wire port XLR input / output;
Display: 1602A LCD display operation panel;
software
Optics
LED type: single white LED 100W;
Light beam angle: 600;
Average life expectancy: ≥50,000H;
Colour
Color temperature: CW 6000K (WW 3200K);
effect
Fast electronic strobe: 1 ~ 25 Hz;
Dimming mode: two kinds;
Dimming curve: four kinds;
Control and Programming
Control channel: two kinds of channel mode (1/2);
Protocol: standard DMX512 protocol, RDM protocol;
Data Connection: waterproof three core wire port XLR input / output;
Display: 1602A LCD display operation panel;
software
Software upgrade: update software via DMX signal easily and quickly upgrade;
Intelligent temperature protection to ensure the LED life;
Light structure
Aluminum structure;
Power and power
Input voltage: AC 100V ~ 240V, 50 / 60Hz;
Rated power: 140W;
other
Protection class: IP 65;
Working environment: -15 ℃ ~ 45 ℃;
size and weight
Lamp Size: 344mm * 220mm * 326mm;
Weight: 9.2 kgs;
Intelligent temperature protection to ensure the LED life;
Light structure
Aluminum structure;
Power and power
Input voltage: AC 100V ~ 240V, 50 / 60Hz;
Rated power: 140W;
other
Protection class: IP 65;
Working environment: -15 ℃ ~ 45 ℃;
size and weight
Lamp Size: 344mm * 220mm * 326mm;
Weight: 9.2 kgs;
